Mitsubishi plc programming cable USB driver software features
1. Supported operating system Windows2000/Windows XP
2. Fully compatible with USB V1.1 and USB CDC V1.1 specifications
3. USB bus power supply (non-isolated cable), or USB bus power supply and PLC programming port power supply at the same time (isolated cable)
4. Baud rate: 300bps～1Mbps automatically adapts
5. Each PC only supports one USB programming cable
Mitsubishi plc programming cable USB driver installation instructions
1. Turn on the power of the computer to which the USB programming cable will be connected, and confirm that the computer's USB port is started and working normally.
2. Plug the USB programming cable into the USB port of your computer. Windows will detect the device and run the Add New Hardware Wizard to help you set up the new device. Insert the driver CD and click Next to continue.
If Windows does not prompt that it found new hardware, in the hardware list of Device Manager, expand "Universal Serial Bus Controllers", select the USB device with the question mark, right-click and run Update Driver.
Mitsubishi plc programming cable USB driver precautions
1. If the USB programming cable plugged into the computer is not detected when the computer is turned on (the COM port corresponding to the cable does not appear in the Windows Device Manager) or other abnormalities occur, please unplug and plug the USB plug again.
2. USB to UART is a plug-and-play USB device. It cannot be disconnected during data transmission (disconnection refers to unplugging the USB cable from the USB socket). That is to say, the cable must be unplugged from the USB socket after the application closes the serial port.
3. Sometimes USB communication abnormalities may occur when the Windows system fails or the USB cable is unplugged and plugged in during communication. In this case, the computer and PLC may need to be restarted.
4. Generally speaking, it is best to plug the USB cable into the USB socket first, and then plug the other end of the programming cable into the PLC communication port after the computer detects the COM port. Because some PLCs work in master station mode, their communication ports are always sending data to me. If you plug the cable into the PLC port first, it will slow down the computer's ability to correctly identify the COM port.
Mitsubishi plc programming cable USB driver FAQ
Question: Mitsubishi plc programming cable USB driver cannot be installed?
Answer: Please check whether your driver CD is in good condition, whether it was installed according to the installation method above, whether the cable is plugged into the computer, and whether the driver has been installed twice.
Question: Can't communicate with the USB driver after installing the Mitsubishi PLC programming cable?
Answer: After the driver is installed, right-click "My Computer" -> "Properties" -> "Hardware" -> "Device Manager" -> double-click "Port" on the desktop. At this time, a new USB (COM port) will be generated in the computer. Then your PLC programming software must be changed to be consistent with this COM port to allow normal communication.
Mitsubishi plc programming cable USB driver system requirements
Before using the USB programming cable, please confirm that your computer is IBM PC compatible and has the following minimum system requirements:
1. Intel compatible 586DX4-100MHz central processor or higher
2. A standard USB interface (4-pin A-type socket)
3. The operating system is Windows 2000 or Windows XP
