R&D engineers can develop their own new features on the Omnific3D CAD platform based on their specific needs. Omnific3D CAD Provides a good design interface to support the dynamic loading and running of plug-ins. Engineers only need to define and implement their own plug-in functions in accordance with the interface specifications, and then they can be well integrated into Omnific3D Run in CAD environment.
Omnific3D CADSoftware features
1. Sketch - point, line, edge, polygon, circle (arc), ellipse (arc), surface, spline.
2. Constraints - parallel, perpendicular, fixed, angle, midpoint, radius, length, distance, coincident, orthogonal, tangent, collinear, equal.
3. Primitive operations - segmentation, cropping, projection, intersection, mirroring, (linear, angular) copy, rounding.
4. Three-dimensional features - extrude, rotate, sweep, loft, cut, divide, fuse, Boolean operations, chamfer (fillet), copy, de-feature.
5. Supports multiple file formats, import and export functions.
6. Support custom plug-ins and extended software.
7. Support command input (tool) operation.
Omnific3D CAD update log
1. Fixed BUG, the new version has a better experience
2. Some pages have been changed
