PRESSCAD latest software introduction
After use, it can help users design hardware molds more easily and conveniently. This software can help users automatically mark model dimensions, annotations, and generate BOM tables. It can also automatically calculate the shear center of the entire set of molds, the required punching shear force, and the punch tonnage, effectively improving the design efficiency. It is a simple, convenient and thorough solution to the layer management problem of die design, which can effectively reduce the work burden of wire cutting personnel and alleviate human errors.
PRESSCAD latest software features
Automatically calculate the shear center of the entire set of molds, the required punching shear force, and the punch tonnage
…
Automatically checking punch position avoids improper design
The convenient and easy-to-use intelligent "mold dictionary" can be used at any time, eliminating the need for text input.
Intelligent fully automatic mold dimensioning function saves you valuable time
Intelligent drawing group management system allows you to create the required standard parts, templates, and mold base information
Powerful duplicate line deletion function and dozens of mold design auxiliary functions
: Wire cutting and corner cleaning functions, automatic threading holes, starting and cutting hole drawing, and wire cutting pricing functions.
Benefit analysis of importing PressCAD system
Can standardize the company's design operations, accumulate design experience, and reduce human errors
Significantly improve mold design efficiency, save costs, and increase productivity
Adopts parametric, graphical operation interface, easy to learn and use, shortens learning time
Fully automatic rotation test to find the most economical way of discharging materials, which has the effect of getting twice the result with half the effort for beginners and professionals.
Easily solve the annoying problem of "design changes"
After the mold drawing is completed, detailed processing instructions and parts and material schedules can be generated
PRESSCAD latest software highlights
1. Human resources
It can shorten the technical training and development time of designers.
大量减少对人工依赖与长期累积经验及技术熟练的技术人员。
2. Competitiveness in mold design and production
Shorten the mold design and manufacturing cycle, reduce production costs, and improve productivity.
It can be flexibly changed according to customer's design change requirements.
Improve the accuracy, quality and reliability of finished products in mold design and manufacturing
Achieving the goal of standardizing mold design and improving credibility with customers.
3. Mold design quality
The mold drawings drawn are clear and easy to interpret, have consistent specifications, and are easy to modify.
Reduce misreading or production errors during on-site mold production.
4. Mold making efficiency
It can ensure the use of data systems such as mold design, processing and database.
We can use the promotion and training of mold design standardization to reduce the style differences in individual mold design.
For a single database, it is easy to connect with the CAM system to generate CNC GM codes to achieve CAD/CAM integration.
PRESSCAD latest update log
1. Optimize content
2. The details are more outstanding and the bugs are gone.
Huajun editor recommends:
The latest installation of PRESSCAD is very simple, powerful, and has no installation garbage. It is specially recommended to everyone. Everyone is welcome to download it! This site also hasHaochen CAD,Yaochuang CAD,Huiyi CAD,vray for 3dmax2015,CAD Viewer, available for you to download!
