Software features
Full process digital integration
Integrate CAD design, CAM programming, path planning, simulation preview and NC code generation functions to support the seamless connection of the entire process from design to processing and reduce data conversion errors.
Multi-axis precision machining capabilities
It supports three-axis, four-axis, and five-axis simultaneous processing, and is especially good at complex curved surface engraving and five-axis precision machining to meet high-end manufacturing needs.
Intelligent path optimization
The built-in intelligent algorithm can automatically optimize the tool path, reduce empty tool travel, improve processing efficiency, and reduce tool wear.
Simulation preview and verification
Provides three-dimensional dynamic simulation function, which can preview tool paths before processing, detect potential collision or overcut risks, and ensure processing safety.
Multi-device compatibility
Supports a variety of mainstream CNC systems and equipment types, including lathes, milling machines, grinders, etc., reducing enterprise equipment adaptation costs.
Advantages of localized services
Provide interface design and localized technical support that fit the habits of domestic users, with fast response and low service costs.
Software function
CAD design functions
It supports two-dimensional drawing, three-dimensional modeling, surface modeling and parametric design, and provides a rich engraving tool library to meet the needs of various processes such as relief, round engraving and openwork engraving.
CAM programming function
Automatically generate efficient tool paths, support multiple strategy combinations of roughing, semi-finishing, and finishing, and the built-in process knowledge base can store commonly used processing parameters.
Simulation and verification functions
Three-dimensional dynamic simulation of the machining process, real-time display of tool and workpiece status, and support for collision detection, overcut inspection and residual height analysis.
Post-processing and code generation
Supports post-processing of multiple types of CNC systems, can output G code, HPGL and other formats, provides code optimization functions, and reduces machine tool idle running time.
Multi-axis machining and five-axis linkage
Specifically optimized for five-axis machining, it supports high-precision machining of complex curved surfaces and special-shaped parts, and is suitable for high-end fields such as aviation and medical care.
Industry customized functions
Provide special tool libraries and process templates for industries such as jewelry, molds, and industrial design, and support user-defined process parameters.
On-machine measurement and intelligent correction
Integrate on-machine measurement technology, collect processing data in real time, support intelligent correction and integration of production and inspection, and improve processing accuracy and production efficiency.
Virtual manufacturing and digital twins
Build a virtual manufacturing environment that is highly consistent with actual production, supporting five-axis process development of a single machine tool and virtual simulation of the entire automated production line.
FAQ
Graphics card driver incompatibility leads to abnormal display
Phenomenon: In relief mode, the brush turns into dense coils or appears gray.
Solution:
Update the graphics card driver to the latest version.
Turn off graphics card acceleration in software settings.
Try using an older graphics card driver.
Line self-intersection points cause display abnormalities
Phenomenon: When making reliefs, lines appear at self-intersection points, resulting in abnormal display.
Solution:
Edit the node and delete the self-intersection point.
Beijing Jingdiao update log:
1. The pace of optimization never stops!
2. More little surprises are waiting for you to discover~
