Software features
Full process digital integration
Integrating CAD design, CAM programming, path planning, simulation preview and NC code generation functions supports the seamless flow of multi-link data and avoids the problem of information islands in traditional processes.
Five-axis precision machining capabilities
Designed specifically for five-axis linkage machining, it supports high-precision processing of complex curved surfaces and special-shaped parts, and is suitable for high-end manufacturing fields such as aviation and medical care.
Intelligent path optimization
The built-in intelligent algorithm can automatically optimize the tool path, reduce empty tool travel, improve processing efficiency, and reduce tool wear.
Simulation preview and verification
Provides 3D simulation function to preview tool paths before processing, detect potential collision or overcut risks, and ensure processing safety.
Multi-device compatibility
Supports a variety of mainstream CNC systems and equipment types, including lathes, milling machines, grinders, etc., reducing enterprise equipment adaptation costs.
Advantages of localized services
As a domestic software, it provides interface design and localized technical support that are more in line with domestic user habits, with fast response speed and low service cost.
Software function
CAD design functions
Supports 2D drawing, 3D modeling, surface modeling and parametric design.
Provides a rich library of engraving tools to meet the needs of various techniques such as relief, round engraving, and openwork engraving.
CAM programming function
Automatically generate efficient tool paths and support multiple strategy combinations of roughing, semi-finishing, and finishing.
The built-in process knowledge base can store commonly used processing parameters and improve programming efficiency.
Simulation and verification functions
Three-dimensional dynamic simulation of the machining process, real-time display of tool and workpiece status.
Supports collision detection, overcut inspection and residual height analysis to ensure processing quality.
Post-processing and code generation
Supports post-processing of multiple types of CNC systems and can output G code, HPGL and other formats.
Provide code optimization function to reduce machine tool idle running time.
Production management function
Support process planning, production scheduling and resource management, helping enterprises achieve lean production.
Provide data statistics and analysis functions to assist enterprises in optimizing production processes.
Industry customized functions
Provide special tool libraries and process templates for industries such as jewelry, molds, and industrial design.
Support user-defined process parameters to meet personalized processing needs.
FAQ
Graphics and line issues:
Line self-intersection points: When making reliefs, lines may have self-intersection points, resulting in abnormal display. Users can resolve this issue by editing the node and deleting the self-intersection point.
Abnormal graphics display: In a 2D environment, the software may freeze or the graphics display may be abnormal. This is usually related to the incompatibility of the graphics card driver.
Software bugs and warnings:
Warning prompts that cannot be eliminated: When making reliefs, warning prompts that are difficult to eliminate may appear. Users can try to eliminate the warning by entering a valid number (such as 1) where the prompt requires a number.
Software compatibility issues: Some versions of Jingdiao software may not support multi-core processors or memory larger than 2G, which may cause the software to run unstable.
Jingdiao software update log:
1: Brand new interface, refreshing, simple and efficient
2: Performance is getting better and better
