OrCAD PSpice electronic circuit simulation software

OrCAD PSPICE circuit simulation softwareIt is a software that can be used in courses such as electronic circuits, circuits, and signals and systems.computer assisted instructionof electronscircuit designSimulation software. The Chinese version of circuit simulation software supports simulation functions,Graphics post-processing functionsand component symbol creation functionSimulation software, used in conjunction with printing plate design software, can realize complete automation of electronic design, with a friendly interface and simple operation. The key is the Chinese version.

Circuit simulation software functions

1. Powerful circuit diagram drawing function

2. Circuit simulation function

3. Graphics post-processing function

4. Simulation software with component symbol production function

5. Can be input graphically

6. Automatic circuit inspection

Circuit simulation software installation method

1. After downloading the OrCAD PSPICE circuit simulation software from this site, get a compressed package locally on your computer. After decompressing it using 360 compression software, double-click the setup.exe file to enter the software installation program, and click [next]

2. Select the installation location of the OrCAD PSPICE circuit simulation software. You can click [browse]. In the window that opens, you can select the software installation location. After completing the selection, click [next].

3. Select the storage location of the OrCAD PSPICE circuit simulation software shortcut, and click [next] after completing the selection.

4. Prepare to install OrCAD PSPICE circuit simulation software, click [next].

5. OrCAD PSPICE circuit simulation software is being installed. You need to wait patiently for the software installation to be completed.

How to localize circuit simulation software:

                                                                                               Unzip the package, first install the OrCAD PSpice main program to the default path, click Next along the way, and then localize the PSpice9_1 file. rar extracted to the installation directory

(The installation directory is generally C:Program FilesOrCAD_DemoPSpice)

Circuit simulation software simulation steps:

1. Double-click to open the OrCAD PSPICE circuit simulation software desktop shortcut, and click [File] after opening the software.

2. Click [new project] in the window that opens, enter the file name, and click [OK].

3. Then a new drawing will be generated.

4. The menu bar at the top of the OrCAD PSPICE circuit simulation software software, the next one is the toolbar, the last line is the PSPice toolbar, and the right side is the drawing toolbar.

5. You can choose to draw the circuit diagram yourself.

Circuit simulation software update log:

1. Fixed other bugs;

2. Optimized software compatibility.
