Pengye installation engineering measurement software

Pengye Installation Engineering Measurement Software is an installation budget measurement software launched by Pengye Software. Pengye Installation Engineering Measurement Software adopts a self-developed CAD platform, which can intelligently analyze the information of drawings, identify and calculate engineering quantities with one click, and accurately and quickly complete various professional installation measurement work, including fire protection, ventilation, water supply and drainage, etc., and can automatically create self-corresponding three-dimensional models. Friends who need it can download and use it.

Main features of Pengye BIM installation calculation software

1. Independent CAD platform

​​​Pengye installation engineering measurement software does not require the installation of CAD software or the need to master CAD operations.

The drawing operation is smooth and smooth, and the response to paper calling and switching is fast

2. Innovative software interface

Pengye installation engineering measurement software is the first measurement software in China to adopt the Ribbon interface style, which is more in line with the requirements of the current mainstream WIN7 operating system.

        Button functions are classified according to majors, so you can know what to do next at a glance

Function buttons are automatically hidden, and almost the entire screen can be used as a graphical display interface

3. Easy to learn and easy to operate

​​A graphical calculation software that is simpler than pricing software. You can easily get started in 10 minutes!

4. It is convenient and simple to check the project quantity

​ CAD electronic drawings and engineering quantity calculation graphics are saved at the same time, allowing you to visually check whether there are any missing engineering quantities;

​​The engineering quantity calculation results and calculation graphics are synchronously positioned and tracked, and the summary result back-checking function facilitates verification and inspection of engineering quantities.

5. One-click mold reversal

      鹏业安装工程算量软件不仅能算量，还能成为您BIM一键翻模的助手。

Calculation results can be directly imported into Revit software to automatically generate BIM data models to improve the efficiency of modeling in Revit software.

The simple and fast "one-click identification" function of Pengye's installation engineering calculation software can also meet the needs of rapid mold reversal only for BIM and serve as a powerful assistant for rapid mold reversal. The software supports Revit2014, 2015, and 2016 versions.

Press the middle mouse button in the graphics area and drag to move the model position; press the Shift key and hold down, press the right mouse button to rotate to rotate the model; save the project, the file suffix will be rvt after saving, the project file is the BIM data model file, the dimensional renderings after importing into Revit are as follows:

​ 6. Drawing partition

​​Pengye installation engineering measurement software defines the attributes of each block of the drawing to ensure that the recognition results are automatically distinguished, without the need for separate manual division

​​​Region locking to achieve selective recognition calculations

7. Dynamic recognition pipeline

Before identifying the water supply, drainage and electrical pipelines, the current circuit will be displayed in advance in the form of yellow highlight to judge whether the circuit is accurate in advance.

​​ 8. One-click device identification

By identifying the equipment legend table, Pengye's installation engineering measurement software can complete the classification and statistics of the quantity of various installed equipment at one time. In actual drawings, the legends in the equipment legend table are incomplete. Many equipment that need to be counted are not included in the equipment legend table. The program lists them as recommended equipment and unknown equipment. You can choose whether to identify them according to the actual situation to ensure that no items are missed when counting the number of equipment.

Pengye installation engineering measurement software update log

1: Brand new interface, refreshing, simple and efficient

2: Performance is getting better and better
