Flow3D

Flow 3D official version is a professional and powerful computational fluid dynamics tool. The Chinese version of Flow3D is built using CFD solution technology, which allows casting engineers to verify the feasibility of the design plan during the design stage, reducing the time and cost of mold modifications. Through Flow3D software, users can accurately and quickly predict the flow of liquids, helping users improve existing processes in the engineering field.

Flow3D software introduction

The Chinese version of flow3d has a variety of physical computer models, including a sediment erosion model, which can simulate erosion phenomena around bridge piers, for example. The air entrainment model can simulate problems such as a small amount of air being entrained in a fluid during flow. In addition, there are shallow water models, ship motion models, etc. The multi-grid block establishment technology provided by flow3d Chinese version enables the downloading and densification of the local grid in the computer area without affecting the number of grids in other computing areas. Multi-grid blocks can use connected or trough-type grid blocks to establish the grid. At the same time, the new version of flow3d adopts the new favor technology, which enables the rectangular grid to describe complex geometric shapes, so that the geometric shapes can be defined efficiently and accurately.

Flow3D software features

      [Meshing and Geometry Meshing Geometry]

Structural finite difference method grid

Multi-block grid technology supports embedded or connected grid blocks

Fractional areas/volumes (FAVOR?) technology can define geometric shapes efficiently and accurately

​ ​ ​ Free Grid Settings

Built-in basic geometry generator

Can read a variety of CAD format drawing files

   【Flow Type Options】

        In-tube flow, out-tube flow, and free surface flow modes

Supports three-dimensional, two-dimensional or one-dimensional problem calculations

Transient flow calculation

Supports Cassis coordinate system or cylindrical coordinate system

Supports inviscid, viscous laminar and turbulent flows

A variety of quantitative numerical calculations

​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​

Two-phase flow

Heat transfer calculation (including phase change)

Saturated and unsaturated porous materials

      [Flow Definition Options]

General initial conditions

       Boundary conditions

Symmetry

Rigid wall

​ ​ Continuous

Cycle

Specified pressure

                                                                                                                                                                                                                                                                     .

Outflow

Grid overlap

Still water

                    Restart options

Continue with simulation calculation

​ Continuation of overlapping calculation data from previous simulation calculations

Add, delete or change model parameters

Flow3D software features

FLOW-3D provides high-precision simulation results faster through our industry-leading truvof algorithm. A pioneering approach to fluid tracking, TruVOF continues to set the industry standard for flow accuracy since its inception 35 years ago. FLOW-3D is the result of collaborations with the world's leading scientific, production and research companies to deliver accurate simulations and efficient collaborative workflows.

Our innovative meshing method, adopted by FLOW-3D™, greatly improves problem setup by embedding geometry directly into the mesh, allowing for rapid parameter adjustments without the labor-intensive meshing required by other CFD software. Engineers spend time visualizing, optimizing, and collaborating on design concepts with streamlined runtimes and more accurate results.

​​​Flowsight provides a powerful and easy way to understand and share simulation results. You can compare results by viewing numerical and visual formats, analyzing ISO surfaces from all six degrees simultaneously, connecting and viewing different cases in the same viewport.

Flow3D update log

The developer of GG said that there are really no bugs this time~
