AutoCAD is a computer-aided design software developed by the American company Autodesk. As the world's leading two-dimensional drawing and three-dimensional design tool, it is widely used in architectural design, mechanical engineering, product design and other fields. It replaces traditional hand-drawing with digital drawing, helping engineers and designers to accurately and efficiently create engineering drawings, build three-dimensional models and compile technical documents, becoming an indispensable standard software in the engineering design industry. Next, let Huajun editor explain to you how to enable hardware acceleration in autocad and how to enable hardware acceleration in autocad!

first step

Open AutoCAD and make sure you are currently in model space (default interface, not layout/paper space).

Step 2

Click the red "A" icon (AutoCAD logo) in the upper left corner of the software. In the expanded menu, select [Options] at the bottom (or directly enter the shortcut key OP and press Enter).

Step 3

In the "Options" dialog box, find and click the [System] tab (located in the top tab bar).

Step 4

Under the "System" tab, find the "Graphics Performance" area and click the [Graphics Performance] button on the right.

Step 5

In the pop-up "Graphics Performance" window:

Check the [Hardware Acceleration] option (if it is already checked, no action is required).

Optional: Adjust other graphics settings (such as "Smooth Display", "Dynamic Coloring", etc., it is recommended to keep the default).

Click [OK] to save the settings.

Step 6

Close and restart AutoCAD and the hardware acceleration feature will be officially enabled.
