AS SSD Benchmark FAQ
How does AS SSD Benchmark see 4K alignment?
1. The following is the test result interface of the editor using AS SSD Benchmark softwarescreenshot, if a red BAD appears when running out of points in the picture, it means that 4K is not aligned.
2. As shown in the figure above, only 4K can give full play to the performance of SSD applications when it is aligned. Otherwise, even if the 4K writing speed is 44/s faster than the mechanical hard disk, it is of little use.
.NET Framework 2.0
It needs to be used with the support of NET Framework 2.0 environment, otherwise an error will be prompted.
AS SSD Benchmark score calculation formula
Comprehensive score = continuous write*0.15 + continuous read*0.1 + 4k single queue depth read*2 + 4k single queue depth write + 4k 64 queue depth write + 4k 64 queue depth read*1.5
Read score = sequential reads * 0.1 + 4k single queue depth reads + 4k 64 queue depth reads
Write score = consecutive writes * 0.1 + 4k single queue depth writes + 4k 64 queue depth writes
AS SSD Benchmark settings Chinese
Automatic switching: When the system language is Chinese, the software will automatically display Chinese after the first run or restart.
Manual setting: Top menu bar Options → Language → select Chinese (Simplified).
Old version processing: If the version is too old and there is no Chinese option, you need to download the Chinese patch or update to the latest version.
AS SSD Benchmark Parameter Interpretation
Seq Read/Write: Continuous reading and writing speed of large files (MB/s).
4K Read/Write: Random small file reading and writing capabilities (MB/s).
4K-64Thrd: multi-threaded random read and write performance (MB/s).
Access Time: Average access delay (ms, the lower the value, the better).
Overall Score: Overall performance score (typically 1000+ points for mainstream SSDs).
AS SSD Benchmark score 100 points
Exception reason:
AHCI mode is not enabled on the SSD or the driver is not installed.
Background programs occupy resources (such as anti-virus software, system updates).
The SSD is old or has a hardware failure.
Troubleshooting steps:
Close all background programs and test again.
Check SSD health status (recommended tool: CrystalDiskInfo).
AS SSD Benchmark tests USB flash drives
Feasibility: The USB flash drive can be recognized and tested, but the results have no reference value.
limitation:
The protocols of U disk interface (USB) and SSD interface (NVMe/SATA) are quite different.
Test parameters (such as 4K performance) do not apply to USB drives.
AS SSD Benchmark software features
Multi-dimensional test mode: supports more than 10 tests such as sequential read and write, 4K random read and write, multi-thread queue depth, etc., covering SSD core performance indicators.
Real-time health monitoring: Automatically detect whether the SSD supports the TRIM command, firmware version and remaining life, assisting users in assessing hardware status.
Visualized result presentation: Display reading and writing speed, access latency, IOPS and other parameters in intuitive charts, and provide a comprehensive score (percentage system).
Lightweight and installation-free: green single-file operation, no need to write to the registry, and supports direct use on portable devices.
Cross-platform compatibility: Compatible with all systems from Windows XP to Windows 11, and compatible with NVMe/SATA/USB interface storage devices.
Advantages of AS SSD Benchmark official version
Accurate performance diagnosis: Through 4K random read and write and other tests, we can accurately locate the bottleneck of SSD in daily use (such as system startup, file decompression).
Free and ad-free: Provides professional-level testing functions completely free of charge, without any payment restrictions or pop-up window interference.
Industry standard reference: The test protocol is complementary to ATTO, CrystalDiskMark and other tools, and the results can be used as a general basis for SSD purchase.
Low operating threshold: complete all tests with one click, no professional knowledge is required to understand the report, suitable for ordinary users to quickly verify performance.
Firmware update assistance: By identifying the SSD model, the user is indirectly prompted whether the official firmware needs to be updated to optimize stability.
AS SSD Benchmark installation steps
1. First, you need to find the download address on this page and select any address to download the AS SSD Benchmark software package locally. As follows:
2. Download the AS SSD Benchmark official version software package to your local computer, double-click and decompress the .EXE format program in the package to run.
3. The official version of AS SSD Benchmark can be opened and used according to the prompts.
AS SSD Benchmark usage tutorial
1. First you need to run and open AS SSD Benchmark.
2. After opening the official version of AS SSD Benchmark, please select the drive letter you want to detect and select the option below the file.
3. After selecting, you will enter the official AS SSD Benchmark testing interface. Please wait patiently for a moment.
4. Finally, after the AS SSD Benchmark official version is tested, we can use the export function to save its data.
More hardware testing software recommendations
CrystalDiskMark：CrystalDiskMark (hard disk testing tool), a compact tool for testing your hard disk or storage device. The simple and easy-to-operate interface allows you to test your storage device at any time. You can choose the size and test number of the storage device, and you can also test the readable and writable speed.
CrystalDiskMark download address:http://softwaredownload4.com/soft/57364.htm
Master Lu: Free hardware detection tool, allowing users to intuitively understand their computer configuration. Not only can it detect computer hardware, but it can also help us detect system vulnerabilities and download corresponding patches in time. In addition, Master Lu can clean up system garbage more cleanly than other tools.
Master Lu download address:http://softwaredownload4.com/soft/76322.htm
AS SSD Benchmark update log
1. Repair NTFS compression
2. Minimum/maximum detection
3. Improved the accuracy of different systems
