PolyBoardSoftware function
1. [2D and 3D views]
PolyBoard displays three 2D views of the cabinet (front, top and side), as well as a 3D rendering associated with material color and texture.
The PolyBoard built-in 3D functionality provides several predefined views, as well as various zoom and rotation tools, which help set the desired 3D view.
PolyBoard also provides DXF 3D_Face export function, compatible with most CAD software, such as AutoCad, VectorWorks, KitchenDraw, etc...
2. [Ramp and Unboxing]
Using PolyBoard, you can design:
前倾斜橱柜，前视图中最多3个不同角度。
Side tilt cabinets.
The unboxed cabinet on the left or right rear.
3. [Cutting List]
The PolyBoard cabinet cut list is recalculated in real time, taking into account the specified material, possible overhangs and plating edge thickness.
Cut lists are exported in OptiCut format, as well as in “Text” format compatible with most spreadsheet and cut optimization software.
4. [Material style]
PolyBoard supports dynamic material style lists: material styles associate different materials with each cabinet component.
After applying another material from the list, the cabinet can be rebuilt using this new material.
The same principle applies to edge styles.
PolyBoardSoftware features
1. [Manufacturing method]
PolyBoard supports a dynamic list of manufacturing methods: the manufacturing method defines all geometric and mechanical cabinet assembly rules.
The manufacturing method also specifies whether the back is applied, grooved, or rake-shaped, determines groove and overlap values, and defines the hardware type for each mating link.
2. [Interactive modification]
一旦机柜采用材料样式和制造方法设计，机柜组件上的“双重clic”将允许其位置，材料或边缘修改。
以同样的方式，拟合链路上的“双clic”将允许其硬件修改。
3. [Tools and Hardware]
For each fit link, the PolyBoard manufacturing method associates the hardware type and positioning rules.
Vertical split tools (side, column, and vertical) follow regular drill group rules, such as type 32. PolyBoard edits a global cabinet hardware summary, as well as tool drawings for each cabinet component.
4.【Post_Processo】
PolyBoard’s Post_Processor is compatible with most CNC machine tools.
PolyBoard generates parameter DXF format (color, line style and layer name), as well as WoodWop MPR (Weeke), Xilog Plus XXL (SCM), BiesseWorks CID (Rover) format.
PolyBoard update log
1. Sweep the bug out and carry it out to the end
2. The most stable version ever
